Automag CAD

[oracleglassarts]

Hey yall, I'm looking for 3d CAD of Automag parts. I found the files listed here:
https://www.zdspb.com/tech/misc/cadf...t/automag.html

Unfortunately, the .sat files posted seem to be incompatible with Solidworks, and Inventor files are certainly incompatible. Does anyone have these as STEP files, or could someone with Inventor please save them as STEPs? Mainly interested in the X-Valve, body, and Intelliframe.

[Ecapnation]

You have to follow a procedure to download.sat files.... I think zds PB hid the procedure as to not have scraper bots take files.

[oracleglassarts]

My understanding was that the text needs to be copied into a text document and saved with the .sat file type, but Solidworks deemed that an unsupported file type and the same happened on a converter that i tried.

ChatGPT thinks its because it was saved from Inventor and that i could manually parse the code to something useable, but I'd rather model from scratch than do that haha.

[superman]

Watch the video.
https://www.youtube.com/watch?v=Cm-3bMTHglk

[oracleglassarts]

You are a true hero, thank you sir.

[cougar20th]

Right click and "save link as" will download them. Then open them in solidworks.

I will warn you I have found those files not to be completely correct. So verify every dimension if you plan on using them for anything more then a rendering.

[oracleglassarts]

Got em, thanks gang!
