    Never had an o ring do this

    Not really looking for help just posting on the wow factor. Had to hammer it out with a dowel.

    Discover the magic of the internet at Imgur, a community powered entertainment destination. Lift your spirits with funny jokes, trending memes, entertaining gifs, inspiring stories, viral videos, and so much more from users.

    #2
    Little dry in there, maybe?

    I cannot say I have seen one do that either.
    feedback

    Comment


      #3
      That o-ring has seen more shredding than Tony Hawk's Pro Skater
      Dulce et decorum est pro comoedia mori

      Comment


        #4
        I see that all the time on the highway. How fast were you going?

        Comment


          #5
          I've seen this several times before when I use to resell paintball gear, primarily for valves like Autocockers where you have to push it past some threads. I suspect that it gets a nick on the side, drys out, and then the compression causes it to split at the weak points.

          Comment


          • Nxt1playr

            Nxt1playr

            commented
            Editing a comment
            I figured that was what had happened since it did have to come out over some treads and with no lube. I also thing the o-rings were oversized as well.

          #6
          O-ring is having a bad hair day.

          Comment


            #7
            This looks like a spiral failure, it happens when a ring is installed improperly (rolled) in addition to/or if a ring is pushed through the tube slowly (and usually without enough lube) where a section of the ring catches on the metal and rolls enough that the rubber shreds itself. To prevent that make sure the tube the valve is being pushed through has lube on it (oil usually works but some lightweight silicone grease can also help) and that the o-ring is also lubed. If you have to pass the valve over threads and it is a snug/tight fit you can pack the threads full of grease to allow the ring to move over them smoothly and then clean the threads out afterward.


            - Planet Eclipse Service Tech / Boston Paintball Service Center / Palmers Pursuit Shop Tech

            Comment


              #8
              I've seen similar O-ring failures with old rubber O-rings and heat... almost as if the O-ring started to melt enough to bond to the indie of the tube.

              I agree that one is probably from being installed twisted, and then jammed past some threads with reckless abandon.

              Filling the threads beforehand is a smart idea when you have to move the valve through them.
              If you need to talk, I will listen. Leave a message and I will call you back as soon as I get it.
              IGY6; 503.995.0257

              Comment


                #9
                It’s fine, just superficial. A little superglue and duct tape will have you runnin in no time.
                FEEDBACK WTB LIST!!!! CLICK NOW

                Comment


                  #10
                  Lolz
                  Attached Files

                  Comment


                    #11
                    I've seen a bunch like that, almost always on valves
